Product Details:
Place of Origin: China
Brand Name: Atlas
Certification: CE,ISO
Model Number: OSS
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: be negotibled
Packaging Details: Atlas standard packing
Delivery Time: 7-30days
Payment Terms: T/T, Western Union, L/C, D/P, D/A
Supply Ability: 100pcs per month

Remove Oil From Air Compressor Condensate With Our Advanced OSS Oil-Water Separator

Description
Material: Aluminum Size: Customized
Filter Element: Pleated Model: MV Series
Type: Inline Inlet/Outlet Connection: NPT
Filter Media: Polyester Connection: Flange
Working Pressure: As Your Working Condition Connection Type: Flange, Thread
Highlight:

Air Compressor Oil-Water Separator

,

Advanced OSS Oil-Water Separator

OSS oil-water separator

An oil-water separation solution for low flow applications facilitates the safe and environmentally friendly treatment of oil in air compressor condensate.
Our OSS provides adsorptive condensate treatment for injectable piston and screw compressors, dryers and oil-water separators with a displacement of less than 30 l / s (60 cu ft / min). The oil separator uses a new advanced filter medium to remove oil, so that the oil concentration is below 15 ppm. To verify the oil concentration at the OSS outlet, an optional sampling kit is available.



Simple and efficient OSS absorption
1.The condensed water enters the OSS through the inlet joint at the top.
2.A pressure-relief port in the top cover allows pressurized condensate to enter the separator.
3.In pre-filtration, the oil-water mixture penetrates the polypropylene filter media, where the oil is absorbed and trapped by the filter media, but the water is not.
4.In the post-filtration phase, advanced filtration media will absorb residual oil.
5.The anti-siphon hole prevents the separator from completely emptying when the flow passes through the outlet joint.
6.The clean condensate coming out of the outlet has almost no residual oil. Therefore, this condensate can be discharged into the sewage pipe.



Characteristics of OSS oil-water separator
The condensate produced by oil-lubricated compressors contains oil and must be handled properly because the oil poses an environmental risk. Atlas Copco condensate management solutions separate and safely dispose of oil from compressor condensate before it enters the sewer system.

Remove Oil From Air Compressor Condensate With Our Advanced OSS Oil-Water Separator 0

Characteristics of OSS oil-water separator
Excellent performance
The advanced oil absorption media used in OSS have the ability to ensure optimal water purity.


Economic solutions
By using our OSS, you no longer have to spend the high cost of hiring an outside company to collect and process cold water.


Full recovery
All materials used in OSS are fully recyclable and therefore can be fully recycled at the end of their useful life.



Technical advantage
1.Clean water
After separation, the oil content in the water is less than 15 ppm, allowing you to safely treat the remaining clean cold water in your wastewater system.
2.Small footprint
The compact, lightweight design makes OSS particularly suitable for space-constrained applications.
3.Easy to install and replace
Wall or plate mounting brackets are standard for easy access and replacement.
