Product Details:
|
| Material: | Aluminum Alloy | Model: | NGP20 |
|---|---|---|---|
| Brand: | Atlas | Nitrogen Purity: | 95-99.9% |
| Air Factor: | 2.6~3.5 | Type: | NITROGEN PSA |
| High Light: | 99.999% PSA Nitrogen Generator,99.99% PSA Nitrogen Generator,99.95% Nitrogen Generator Atlas |
||
A secure supply of nitrogen and oxygen
Whether your company is specialized in chemical manufacturing, electronics, laser cutting or food and
beverage, a dependable supply of industrial gas is crucial. Compared to the on-demand delivery of gas bottles
or tanks, on-site production of gas offers a wealth of advantages ranging from cost savings to continuous
availability. Atlas ’s advanced nitrogen and oxygen generators offer you the ultimate solution: flexible
on-site production of industrial gas at the lowest possible cost.
All-in-one high pressure nitrogen skid
The latest addition to Atlas ’s specially developed equipment is the all-in-one high pressure nitrogen
skid, a true alternative for liquid nitrogen or bottles. Combining a small footprint, easy installation, high reliability and supreme energy efficiency, this unique nitrogen skid truly stands out.
The all-in-one solution
All nitrogen skid components are built to Atlas quality and efficiency standards. They are tested for optimal performance and reliability.
Specifications
| TYPE | Nitrogen purity FND (Free Nitrogen Delivery) | Dimensions (W x D x H) | Weight | ||||||||||||
| 95% | 97% | 98% | 99% | 99.5% | 99.90% | 99.95% | 99.99% | 99.999% | mm | in | kg | lbs | |||
| NGP 20 | FND scfm | 26.3 | 20.5 | 17.2 | 13.2 | 10.7 | 6.9 | 5.2 | 3.6 | 2.0 | 798 x 840 x 2022 | 31.4 x 33.1 x 79.6 |
306
|
675
|
|
| FND Nm³/h | 44.7 | 34.9 | 29.3 | 22.5 | 18.2 | 11.8 | 8.9 | 6.1 | 3.4 | ||||||
FND: Free Nitrogen Delivery Reference conditions
Compressed air effective inlet pressure: 8 bar(g)/116 psi(g).
Nitrogen outlet pressure: 6.5 bar(g)/94 psi(g).
Ambient air temperature: 20°C/68°F.
Pressure dewpoint inlet air: 3°C/37°F.
Pressure dewpoint nitrogen: -50°C/-58°F.
Minimum refrigerant dryer required to precondition inlet air.
Typical nitrogen quality 1.2.1 according to ISO 8573-1:2010.
Operating limits
Minimum ambient temperature: 5°C/41°F.
Maximum ambient temperature: 50°C/122°F.
Maximum compressed inlet air pressure 13 bar(g)/189 psi(g).
NGMs performance
is based on 20°C/7 bar at membrane (1000Mbar) + /-5%.
