Product Details:
Place of Origin: China
Brand Name: Atlas
Certification: CE,ISO
Model Number: ZR/ZT 75-160 VSD+
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: be negotibled
Packaging Details: Atlas standard packing
Delivery Time: 7-30days
Payment Terms: T/T, Western Union, L/C, D/P, D/A
Supply Ability: 100pcs per month

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries

Description
Voltage: 380v/3ph/50hz(or Customized) Condition: New
Lubrication Style: Oil-free Warranty: 1 Year
Type: Oil-free Cooling Method: Air Cooling
FF Available: Built-in Dry Available Pressure: 4-10.4bar
High Light:

160 VSD+ Screw Air Compressor

,

Critical Industries Screw Air Compressor

,

Atlas Screw Air Compressor

Oil-free air rotary screw compressor

ZR/ZT 75-160VSD+





Setting the standard in energy efficiency, safety and reliability
The shortest route to superior productivity is to minimize operational cost while maintaining an uninterrupted supply of the right quality of air. The Atlas Copco Z compressor series is focused on efgectively saving energy, ensuring product safety – only oil-free machines exclude contamination risks for 100%– and guaranteeing the utmost reliability around the clock. And not just today, but day afuer day, year afuer year, with minimal maintenance cost, few service interventions and long overhaul intervals.





Reliability

Reliable element

• Next generation world class compression element.
• Atlas Copco superior rotor coating for high durability.
• Thermal efgiency reduces the expansion leading to reduces wear and increased reliability.
• More compact, improved rotor profiles and cooling jackets for maximum durability.



Advanced touch screen monitoring system
• User-friendly Elektronikon® Touch, with enhanced connectivity potential.
• Included warning indications, maintenance scheduling and online visualization of the machine’s condition for increased reliabiltiy.



Highly reliable motor
• IP66 Permanent Magnet water cooled motor with oil lubricated bearings.
• Rock-solid reliability prevents dust and water entering the motor.



Zero loss drains

• Clearance of all water & contamination
• Increasing both product & system reliability.



Easy access
• Easy access to all components to minimize maintenance times.
• Hinged doors for easy routine maintenance e.g. cleaning.
• Saves valuable and ofuen expensive floor space in a facility.
• Highest ratio flow/footprint on the market.



Soundproof design
• Silenced canopy ensures optimal working conditions for everyone in the immediate environment.
• Optimized internal ducting and integrated pulsation damper to reduce the noise level.
• High quality coated canopy to prevent rust.



Grouped service items
• Minimal service time because service parts are grouped together for ease of access.
• All components are designed for serviceability and long lasting lifetime.


Realiable control - NEOS drive

• Atlas Copco NEOS inverter designed to work in the harsh conditions of the compressor house.
• Modular design allows replacement of individual components, reducing maintenance cost.
• Cubicle designed to keep the inverter cool extending the lifetime & increase operational efgiciency.


Reliable cooling

• Cooler with highly efgicient water separator for higher reliablity.
• Stainless steel enlarged surface coolers to ensure top performance over a long lifetime.
• Pipes with star profile form bi-anodised aluminium for preventing corrosion.
• Easily removable for quick, cost-efgicient maintenance.







Optimize your system
With the ZR/ZT, Atlas Copco provides an all-in-one standard package incorporating the latest technology in a built-to-last design. To further optimize your ZR/ZT’s performance or to simply tailor it to your specific production environment, optional features are available.

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 0







Flowchart
Process flow, oil flow and cooling flow - step by step

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 1

1. Filtration & compression

The air is drawn into the compressor through the inlet filter where the air is cleaned.
It then continues to the first compression stage where the air is compressed to an intermediate pressure.



2. Cooling & second compression
Afuer the first compression, the air is cooled down in the intercooler. Once the air is cooled down, it passes through a moisture separation system before entering the high-pressure stage. In the high-pressure stage, the pressure is brought to its final pressure.



3. Exchanging heat & cooling
The hot wet compressed air at the outlet of the high-pressure stage goes through the pulsation damper with integrated check valve to the heat exchanger. Here it transfers the heat to the integrated dryer used further in the process.
The air continues to the afuercooler where it's cooled down and the moisture get's separated and drained.



4. Integrated dryer
The cooled wet compressed air is now mixed with 40% of the cooled regeneration air and enters the dryer. The dry compressed air with guaranteed dew point is now ready for use in your application.



5. Heat exchanger

40% of the dry air goes into the heat exchanger, where it picks up the heat from the incoming hot wet compressed air. This dry and hot regeneration air enters the regeneration section of the drum, which passes through the regeneration cooler where it is cooled down and moisture is separated and drained. Afuerwards it is mixed with the incoming cooled wet compressed air.



6. Oil
The yellow lines represent the oil flow of the compressor.Oil is pumped from the reservoir through a high efgiciency filter to provide clean, cooled oil to the gears for lubrication. Afuerwards the oil flows back into the reservoir.
There also is a bypass valve that allows the oil to flow to the oil cooler, so the optimal temperature is guaranteed,increasing efgiciency and durability of our components.



7. Water
The dark blue lines represent the water flow. Cooling water is brought into the cycle and splits towards the both modules and the dryer.
First of all, the cooling water is directed to the integrated dryer to cool the
Secondly, the water is goes to both the inter- and afuercooler to reduce the temperature of the compressed air.
Lastly, the water splits to the oil coolers to reduce the temperature of the oil. It then passes through the jackets of the motor and elements to guarantee an optimal temperature. The water continues back to the cooler and is directed further to the water outlet.

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 2ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 3

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 4ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 5









Technical specifications
Data of the ZR/ZT 75-160 VSD+ (FF) range

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 6

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 7



ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 8

ZR/ZT 75-160 VSD+ Atlas Oil Free Screw Air Compressor The Best Choice For Critical Industries 9
