Product Details:
Place of Origin: China
Brand Name: Atlas
Certification: ISO 8573-1 CLASS 0
Model Number: GA 200
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: be negotiated
Packaging Details: Atlas standard packing
Delivery Time: 7~30days
Payment Terms: L/C, T/T, D/A, Western Union, D/P
Supply Ability: 100pcs per month

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary Atlas Screw Air Compressor

Description
Material: Aluminum Alloy Model: GA 200+ - 10 Bar
Power: 200kw Brand: Atlas
Type: Oil-injected System: SIL Smart Inlet Lock System
High Light:

Rotary Screw Atlas GA Series

,

GA200 Atlas GA Series

,

200kw Atlas GA200

200kw Atlas Ga200 Air Compressor Oil-Injected Rotary Screw



INCREASE YOUR SAVINGS WITH
ENERGY RECOVERY

The Kyoto directives and the continuing depletion of traditional energy sources mean that businesses throughout the world are making commitments to significantly reduce overall energy consumption. Through innovative products and solutions, Atlas helps you achieve your goals in this area. When it comes to compressed air production – where energy costs can constitute 70% of total lifecycle costs
– saving energy can also lead to substantial cost savings.





Integrated heat exchanger
Air compression creates heat that is normally wasted in the coolers. Energy recovery systems designed by Atlas enable the recovery of most of this heat. Recovery of energy from the shaft input of the compressor can be up to 94% of the compressor
shaft power. The heat is directly usable as a source of energy in the form of hot water (85-90°C/185- 194°F). The main module of the recovery system is built into the compressor. The investment needed to link the hot oil circuit from the compressor to the existingwater circuit is relatively modest and the time needed before seeing payback from your investment is generally very short.

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 0



























Warm air heat recovery
The ducting on your GA compressors also constitutes a simple and smart solution to generate space heating. Ducting simply directs the warmed cooling air to where it is needed – such as workshops, storage warehouses or other facilities. To cope with seasonal changes, louver flaps can be used to vent the warm air to the outside. An installation with motorized and thermostatically
controlled louvers is the ideal solution to accurately monitor the temperature with a full control of the flow of heating air.


Applications:
• Heating of facilities, warehouses or workshops.
• Drying air for painting and washing applications.



Integrated heat exchanger
Air compression creates heat that is normally wasted in the coolers. Energy recovery systems designed by Atlas enable the recovery of most of this heat. Recovery of energy from the shaft input of the compressor can be up to 94% of the compressor
shaft power. The heat is directly usable as a source of energy in the form of hot water (85-90°C/185- 194°F). The main module of the recovery system is built into the compressor. The investment needed to link the hot oil circuit from the compressor to the existingwater circuit is relatively modest and the time needed before seeing payback from your investment is generally very short.



MONITORING AND CONTROL:
HOW TO GET THE MOST FROM THE LEAST

The Elektronikon® unit controller is specially designed to maximize the performance of your compressors and air treatment equipment under a variety of conditions. Our solutions provide you with key benefits such as increased energy efficiency, lower energy consumption, reduced maintenance times and less stress… less stress for both you and your entire air system.

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 1

Intelligence is part of the package
• High resolution color display gives you an easy to understand readout of the equipment’s running conditions.
• Clear icons and intuitive navigation provides you fast access to all of the important settings and data.
• Monitoring of the equipment running conditions and maintenance status; bringing this information to your attention when needed.
• Operation of the equipment to deliver specifically and reliably to your compressed air needs.
• Built in remote control and notifications functions provided as standard, including simple to useEthernet based communication.
• Support for 31 different languages, including character based languages.

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 2




Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 3
Mining industry
• Years of experience with thousands of compressors running around the world.
• High product reliability with maximum uptime even in harsh conditions.
• Strong global support network to provide 24/7 assistance even in remote locations.




Energy industry
• Protect downstream equipment and increase component lifetime.
• Integrated water separator with electronic drain as standard.



Metal industry
• Easy and quick installation, with flexible ducting possibilities.
• A complete, ready-to-use solution including all components and options.
• Low service cost thanks to high accessibility of components and long service intervals.



General industry
• GA compressors are designed for ultimate efficiencyin all your industrial applications.
• Ideal for machinery operation, plant maintenance, cleaning,pneumatic tools and controls, sand- and shot-blasting.





Online & mobile monitoring
Monitor your compressors over the Ethernet with the Elektronikon® unit controller. Monitoring features include warning indications, compressor shut-down and maintenance scheduling. An Atlas App is available for iPhone/Android phones as well as iPad and Android tablets. It allows fingertip monitoring of your compressed air system through your own secured network.


Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 4
Full optimization -ES system controller
Improve product quality every minute that your facility is in operation.Atlas 's ES system controllers offer a convenient way to achieve optimized performance from your low pressure equipment through a single centralized point of monitoring and control. With the ES system controller watching over your compressors and compressed air network, you will have a highly dependable and energyefficient solution working with your facility to manage operating costs.



Dual pressure set-point and Delayed Second Stop
Most production processes create fluctuating levels of demand which, in turn, can create energy waste in low use periods. Using the graphic Elektronikon® unit controller, you can manually or automatically create two different system pressure bands to optimize energy use and reduce costs at low use times. In addition, the sophisticated Delayed Second Stop (DSS) runs the drive motor only when needed. As the desired system pressure is maintained while the drive motor’s run time is minimized, energy consumption is kept to a minimum.
Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 5



SMARTLINK*: Data Monitoring Program
• A remote monitoring system that helps you optimize your compressed air system and save you energy and cost.
• It offers you a complete insight in your compressed air network and anticipates on potential problems by warning you up-front.

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 6



FLOW CHARTS
Fixed speed: GA+ & GA

Energy-Saving Solutions for GA Series GA200 Oil-Injected Rotary  Atlas Screw Air Compressor 7
