Product Details:
|
| Machine Type: | Oil Injected Screw Air Compressor | Model: | G37~90 |
|---|---|---|---|
| Motor: | IE3 Premium Motor | Frequency: | 50~60Hz |
| Motor Power: | 37~90kw | Working Pressure: | 7.5~13 Bar |
| High Light: | G Series Atlas Rotary Screw,G45 37kw Atlas Rotary Screw,90kw Atlas G45 |
||
Atlas Rotary Screw G Series 37~90kw G45 Oil Injected 7.5-13bar Working Pressure
Click to open our catalog:G2-90 wuxi leaflet EN 2935081343.pdf
High Reliability And Smart Energy G37/G45/G55/G75/G90
Maintenance-free drive system
•100% maintenance-free; totally enclosed and protected against dirt and dust.
• Suitable for harsh environments.
• High-efficiency drive arrangement; no coupling or slippage losses.
• Standard up to 46˚C/115˚F and for high ambient version 55˚C/131˚F.
IE3 Premium Efficiency electrical motors
• IP55, insulation Class F, B rise.
• Non-drive side bearing greased for life.
• Designed for continuous operation in harsh environments.
Robust spin-on oil filter
• High-efficiency, removing 300% smaller particles than a conventional filter.
• Integrated bypass valve with the oil filter.
SIL Smart inlet lock system for GA VSD compressors
• Superior designed vacuum and air pressure controlled valve with minimal pressure drop and no springs.
• Smart stop/start which eliminates back-pressure oil vapor.
Separate oversized oil cooler and aftercooler
• Low element outlet temperatures, ensuring long oil lifetime.
• Removal of nearly 100% condensate by integrated mechanical separator.
• No consumables.
• Eliminates possibility of thermal shocks in coolers.
Electronic no-loss water drain (optional)
• Ensures constant removal of condensate.
• Manual integrated bypass for effective condensate removal in case of power failure.
• Integrated with compressor’s Elektronikon ® with warning/alarm features.
Heavy-duty air intake filter
• Protects the compressor components by removing 99.9% of dirt particles down to 3 microns.
• Differential inlet pressure for proactive maintenance while minimizing pressure drop.
Elektronikon ® for remote monitoring
• Integrated smart algorithms reduce system pressure and energy consumption.
• Monitoring features include warning indications, maintenance scheduling and online visualization of machine’s condition.
Cubicle cooling booster
• Cubicle in overpressure minimizes ingress of conductive dust.
• Electrical components remain cool, enhancing lifetime of components.
NEOS drive
• Atlas ’s in-house designed inverter for GA VSD compressors.
• IP5X protection degree.
• A robust, aluminum enclosure for trouble- free operation in the harshest conditions.
• Fewer components: compact, simple and user-friendly.
Integrated highly efficient R410A dryer
• Excellence in air quality.
• 50% reduction in energy consumption compared to traditional dryers.
• Zero ozone depletion.
• Incorporates optional UD + filter according to Class 1.4.2.
Specifications
| COMPRESSOR TYPE |
Pressure variant (bar) |
Max. working pressure WorkPlace |
Capacity FAD* | Installed motor power | Noise level** |
Weight WorkPlace |
Weight WorkPlace Full Feature |
|||
| bar(e) | psig | l/s | m³/min | cfm | kw | dB(A) | kg | kg | ||
| G37 | 7.5 | 7.5 | 109 | 116 | 6.9 | 243 | 37 | 67 | 683 | 853 |
| 8.5 | 8.5 | 123 | 108 | 6.5 | 226 | 37 | 67 | 683 | 853 | |
| 10 | 10 | 145 | 100 | 6 | 210 | 37 | 67 | 683 | 853 | |
| 13 | 13 | 189 | 88 | 5.3 | 185 | 37 | 67 | 683 | 853 | |
| G45 | 7.5 | 7.5 | 109 | 138 | 8.3 | 290 | 45 | 70 | 692 | 900 |
| 8.5 | 8.5 | 123 | 128 | 7.7 | 268 | 45 | 70 | 692 | 900 | |
| 10 | 10 | 145 | 119 | 7.2 | 251 | 45 | 70 | 692 | 900 | |
| 13 | 13 | 189 | 105 | 6.3 | 221 | 45 | 70 | 692 | 900 | |
| G55 | 7.5 | 7.5 | 109 | 169 | 10.1 | 359 | 55 | 69 | 1329 | 1429 |
| 8.5 | 8.5 | 123 | 159 | 9.5 | 337 | 55 | 69 | 1329 | 1429 | |
| 10 | 10 | 145 | 148 | 8.9 | 313 | 55 | 69 | 1329 | 1429 | |
| 13 | 13 | 189 | 126 | 7.6 | 267 | 55 | 69 | 1329 | 1429 | |
| G75 | 7.5 | 7.5 | 109 | 226 | 13.6 | 478 | 75 | 73 | 1371 | 1491 |
| 8.5 | 8.5 | 123 | 209 | 12.5 | 444 | 75 | 73 | 1371 | 1491 | |
| 10 | 10 | 145 | 190 | 11.4 | 401 | 75 | 73 | 1371 | 1491 | |
| 13 | 13 | 189 | 162 | 9.7 | 344 | 75 | 73 | 1371 | 1491 | |
| G90 | 7.5 | 7.5 | 109 | 281 | 16.9 | 596 | 90 | 73 | 1525 | 1645 |
| 8.5 | 8.5 | 123 | 275 | 16.5 | 582 | 90 | 73 | 1525 | 1645 | |
| 10 | 10 | 145 | 250 | 15 | 529 | 90 | 73 | 1525 | 1645 | |
| 13 | 13 | 189 | 216 | 13 | 458 | 90 | 73 | 1525 | 1645 | |
* Unit performance measured according to ISO 1217, Annex C, Edition 4:2009.
Reference conditions:
• Absolute inlet pressure 1 bar (14.5 psi)
• Intake air temperature 20°C, 68°F
FAD is measured at the following working pressures:
• 7.5 bar versions at 7 bar
• 8.5 bar versions at 8 bar
• 10 bar versions at 9.5 bar
• 10.5 bar serion at 10 bar
• 13 bar versions at 12.5 bar
