Product Details:
|
| Material: | Aluminum Alloy | Model No: | OGP 3+-30+ |
|---|---|---|---|
| Brand: | Atlas | Type: | PSA Generators |
| Advantage: | 30% Less Feed Air Than Traditional Generator | Oxygen Purity: | 90-95% |
| Power Supply: | Electricity | Weight: | 318-1298kg |
| Highlight: | Revolutionary Engineering Oxygen Generator Atlas,Modular Design Oxygen Generator Atlas,On-Site Oxygen Generator Atlas |
||
Specifications
| Type | Oxygen FOD | Dimension | Weight | |||||
| 90% | 93% | 95% | mm | in | kg | lbs | ||
| OGP 3+ | FOD Nm³/h | 3.3 | 3.0 | 2.5 | 796x840x2015 | 31x33x79 | 318 | 701 |
| FOD Scfm | 1.9 | 1.8 | 1.5 | |||||
| OGP 6+ | FOD Nm³/h | 6.6 | 6.0 | 5.1 | 796x840x2015 | 31x33x79 | 400 | 882 |
| FOD Scfm | 3.9 | 3.6 | 3.0 | |||||
| OGP 9+ | FOD Nm³/h | 10.0 | 9.4 | 8.3 | 1421x840x2015 | 56x33x79 | 624 | 1376 |
| FOD Scfm | 5.9 | 5.5 | 4.9 | |||||
| OGP 12+ | FOD Nm³/h | 13.3 | 12.5 | 11.1 | 1421x840x2015 | 56x33x79 | 706 | 1556 |
| FOD Scfm | 7.8 | 7.4 | 6.5 | |||||
| OGP 15+ | FOD Nm³/h | 16.6 | 15.7 | 13.9 | 1421x840x2015 | 56x33x79 | 788 | 1737 |
| FOD Scfm | 9.8 | 9.2 | 8.2 | |||||
| OGP 18+ | FOD Nm³/h | 19.7 | 18.1 | 15.2 | 1421x970x2015 | 55x38x79 | 970 | 2138 |
| FOD Scfm | 11.6 | 10.7 | 8.9 | |||||
| OGP 24+ | FOD Nm³/h | 26.3 | 24.1 | 20.3 | 1421x970x2015 | 56x38x79 | 1134 | 2500 |
| FOD Scfm | 15.5 | 14.2 | 11.9 | |||||
| OGP 30+ | FOD Nm³/h | 32.9 | 30.2 | 25.3 | 1421x970x2015 | 56x38x79 | 1298 | 2862 |
| FOD Scfm | 19.3 | 17.8 | 14.9 | |||||
FOD: Free Oxygen Delivery
Reference conditions:
- Compressed air effective inlet pressure: 6 bar(g)/87 psi(g)
- Ambient air temperature: 20°C/68°F
- Inlet air quality [1:4:1] according to ISO 8573-1:2010
- Outlet oxygen quality [1:2:1] according to ISO 8573-1:2010
Options
- Low ambient temperature settings (-10ºC/14ºF)
- Oxygen quality (PDP) monitoring
- Room oxygen alarm (wall mount)
Advanced features, superior benefits
• Complete machine with O 2 sensor, digital flow meter, and pressure regulator included as standard.
• Small footprint thanks to:
- Best-in-class usage of zeolite molecular sieve (ZMS) adsorbent material.
- Intelligent-design and approval-friendly aluminum extrusions.
• Advanced controller with large HD color touchscreen offers easy gas purity selection, purity alerts, and connectivity options.
• Automatic start-up allows for plug-and-play installation.
• Feed air monitoring and interception.
• Oxygen purity monitoring and interception.
The zirconia oxygen sensor’s long lifetime reduces service intervention needs and costs.
Click to open the catalog:OGP+_3-30_antwerp_datasheet_EN_2935097141.pdf
